19×40W IP65 LED Wash Moving Head

19x40w led moving head wash ip65
19x40w led moving head wash ip65 waterproof – outdoor pixel wash light
19x40w led moving head wash ip65 waterproof – outdoor pixel wash light
19x40w led moving head wash ip65 waterproof – outdoor pixel wash light
19x40w led moving head wash ip65 waterproof – outdoor pixel wash light
19x40w led moving head wash ip65 waterproof – outdoor pixel wash light
19x40w led moving head wash ip65 waterproof – outdoor pixel wash light
Categories , Tags , , , , , , ,
Model
AL1940WP

The AL1940WP is listed as an IP65 LED wash fixture with 19 RGBW 4-in-1 LEDs, 7°–50° motorized zoom, pixel control and DMX512 modes. Confirm installation requirements and current documentation before outdoor deployment.

Request a 19×40W IP65 Quote

Review the IP65 outdoor buyer guide, browse the LED Wash range, or discuss your outdoor project.

GET A QUOTE
USER MANUAL

Technical Specifications

Function Highlights

Application Scenarios

Packaging Options

Product Details:



https://www.youtube.com/watch?v=XKc3yhKju-4



🛠️ Technical Specifications

Specification Details
Model AL4019WP
Input Voltage AC100V~240V, 50/60Hz
Rated Power 760W
LED Source 19×40W RGBW 4-in-1 High Power LEDs
Zoom Range 7° – 50° Motorized Zoom
Strobe 0–25Hz Electronic Strobe
Control Modes DMX512, Sound-activated, Master/Slave
DMX Channels 22/26/36/43/78/119 Channel Modes
Dimmer 0–100% Linear (4 dimmer curves)
Pan/Tilt 540° / 250° + 16-bit fine adjustment
Display LCD Touch Screen
Protection Rating IP65 (Waterproof for Outdoor Use)
Fixture Dimensions 434×260×577 mm
Net Weight 22 kg

💡 Function Highlights

    • Individual LED Pixel Control
      Full pixel mapping with 19 independently controlled LEDs for advanced visual programming.

    • Rotating Front Lens (Infinite Rotation)
      Unique bidirectional rotating lens delivers dynamic kaleido and vortex effects.

    • Beam + Wash + Kaleido Effects
      Combines tight beam, wide wash, and artistic visual modes into one fixture.

    • Halo Ring Effects
      Built-in halo rings create eye-catching candy effects with macro control options.

    • Weatherproof Design (IP65)
      Engineered with die-cast aluminum housing to withstand rain, dust, and harsh outdoor environments.

    • Wide Zoom (7°–50°)
      From narrow beam to wide wash, covers small to large areas with even color wash.

🎯 Application Scenarios

Aolait AL4019WP is a professional-grade 19x40W LED moving head wash light designed for outdoor use with full IP65 waterproof protection. Featuring individually controllable pixels, infinite rotating lens, and powerful zoom from 7° to 50°, it delivers stunning beam, wash, and kaleido effects — perfect for concerts, festivals, architectural lighting, and permanent installations.

    • Outdoor Music Festivals
      Powerful beam and effect lighting for dynamic stage impact in open-air environments.

    • Architectural Lighting
      Illuminate buildings, monuments, and structures with color washes and movement.

    • Theme Parks & Public Spaces
      Add animated lighting elements that withstand rain and environmental challenges.

    • Touring & Rental Events
      A flexible wash/beam hybrid for lighting designers needing durability and high performance.

    • Churches & Worship Events (Outdoor)
      Wash large outdoor stages or create immersive atmospheres for spiritual gatherings.

📦 Packaging Options

Carton 1 in 1: 61x53x54cm 26kgs
