Compact and full-featured, the AL150LS 150W LED Spot Moving Head delivers vibrant colors, layered gobo effects, and precise movement—perfect for DJs, events, and stage shows.
| Specification | Details |
|---|---|
| Model | AL150LS |
| Input Power | AC100–240V, 50/60Hz |
| Power Consumption | 170W |
| LED Source | 1x 150W White LED |
| Beam Angle | 16° |
| Pan Movement | 540° (16-bit with Electric Correction) |
| Tilt Movement | 270° (16-bit with Electric Correction) |
| DMX Channels | 16 Channels |
| Control Mode | DMX512 / Master-Slave / Auto Run |
| Color Wheel | 1 wheel with 7 color chips |
| Static Gobo Wheel | 7 Gobos + Open |
| Rotating Gobo Wheel | 6 Gobos + Open |
| Effect Wheel | 3-Facet Rotating Prism + Frost |
| Focus | Mechanical Focus Lens |
| Dimmer | 0–100% Linear Dimming |
| Strobe | 0–20Hz Electronic Strobe |
| RDM | Supported |
| Display | LCD Screen |
| Overheat Protection | Yes |
| Net Weight | 9.5 kg |
Bright & Consistent 150W LED Source: High-efficiency LED delivers brilliant output and long lifespan.
Dual Gobo Wheels (Static + Rotating): Layered gobo effects and sharp patterns for custom projection.
Color Wheel with 7 Vibrant Hues: Instant color changes and split color effects.
Rotating 3-Facet Prism + Frost Filter: Create stunning mid-air effects or soften for wash-like output.
Smooth 16-Bit Pan/Tilt Movement: Quiet and precise positioning with electric correction.
DMX, Master/Slave & Auto Run Modes: Flexible control options for any lighting setup.
RDM Protocol Support: Remote management and monitoring for advanced setups.
Efficient Thermal Management: Built-in overheat protection ensures long-term reliability.
Compact yet powerful, the AL150LS 150W LED Spot Moving Head offers precise movement, vivid gobos, and versatile stage effects, making it a perfect choice for small-to-medium venues, clubs, and mobile DJs.
Live Shows & Concerts: Vivid gobos and movement for powerful stage dynamics.
Nightclubs & Bars: Eye-catching spot effects and color transitions.
Church Events: Quiet, reliable operation with crisp projections for sermons and worship.
Weddings & Banquets: Custom patterns and frosted wash effects for elegant ambiance.
Mobile DJ Setups: Lightweight and portable for easy transport and setup.
Theaters & Studios: Precise optics for mood lighting and scene changes.
Carton 1 in 1 :48 x 37 x 28 cm GW 11kgs
