The AL550RX 550W Beam Spot Wash Moving Head features PHILIPS 480W lamp, CMY mixing, 2 prism wheels, and full zoom range. Designed for high-end stage and touring.
| Specification | Value |
|---|---|
| Model | AL550RX |
| Voltage | AC100-240V, 50-60Hz |
| Power | 800W |
| Light Source | PHILIPS MSD Silver 480W LL |
| Color Temperature | 7500K – 8500K |
| Lamp Lifespan | 4000 hours |
| Control Protocol | DMX / Master-Slave / Auto / Sound |
| DMX Channels | 34CH / 39CH |
| Pan | 540° + fine (Magnetic Encoder) |
| Tilt | 270° + fine (Magnetic Encoder) |
| Beam Mode Angle | 1.6°–22° |
| Spot Mode Angle | 2.9°–44° |
| Dimmer | 0–100% smooth linear |
| Strobe | 1–25Hz with pulse effect |
| Color Wheel | 13 dichroic filters + white |
| Virtual Color Wheel | Linear CMY + 66 preset colors |
| Static Gobo Wheel | 14 gobos (10 metal + 4 reducers) + open |
| Rotating Gobo Wheel | 9 gobos + open |
| Prism Wheel 1 | 6-facet linear, 8-facet circular (12°), cylindrical prism – all rotating bi-directionally |
| Prism Wheel 2 | 6-facet linear, 32-facet circular, 8-facet circular (18°) – all rotating bi-directionally |
| Frost | With frost effect |
| Focus | Motorized focus |
| Display | Full-color LCD display |
| Fixture Size | 391 × 230 × 673 mm |
| Net Weight | 21.5 kg |
3-in-1 Hybrid Design: Beam, Spot, and Wash effects in a single fixture.
Wide Zoom Range: 1.6° tight beam to 44° wash coverage.
Professional Gobos: Dual gobo wheels (rotating and static) for sharp aerial projection and textures.
Double Prism Wheels: Six prisms total for multidimensional effects, all bi-directionally rotatable.
CMY + 13-Color Wheel: Full color mixing plus built-in 66-color presets.
High Output Optical System: Engineered specifically for PHILIPS 480W LL lamp.
The AL550RX is a high-performance 3-in-1 Beam Spot Wash moving head light powered by the PHILIPS MSD Silver 480W LL lamp. With a zoom range from 1.6° beam to 44° wash, dual rotating prisms, full CMY mixing, and sharp aerial gobos, it’s designed for advanced stage applications requiring precision, creativity, and power.
Concert Touring & Arena Shows: Beam and aerial effects cut through large venues.
Theater & Performing Arts: Spot precision and silent color fades enhance scenes.
Nightclubs & Festivals: Sharp gobos, vibrant prisms, and fast strobing energize dance floors.
Worship & Church Events: Smooth dimming and quiet operation for reverent spaces.
Weddings & Corporate Events: Dazzling visual transitions and color washes add elegance and impact.
Rental Companies: Long-life lamp and robust engineering ensure reliable ROI.
Carton 1 in 1 :65x60x49.5cm GW:27KG
Flight case 2 in 1:69.x51x89cm GW:77KG
